CE Loader Machine Four Wheel Drive Loader 13.5HP Small Front End Loader Mini Skid Steer Loader
| Place of Origin | China |
|---|---|
| Brand Name | Jawell |
| Certification | CE |
| Model Number | JW-MLM-HT360-HT |
| Minimum Order Quantity | 1 piece |
| Price | $3700--$3932 |
| Packaging Details | Export wooden packaging |
| Delivery Time | 7-35days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 3000 pieces per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Engine Brand | Xinchai | Power | 17.2 Kw |
|---|---|---|---|
| Applicable Industries | Building Material Shops, Farms, Home Use, Construction Works , Construction Agriculture | Type | Skid Steer Loader |
| Warranty | 1year | Machine Weight | 890 Kg |
| Hydraulic Pump Brand | Eougem | UNIQUE SELLING POINT | Long Lifetime |
| Machinery Test Report | Provided | Video Outgoing-inspection | Provided |
| Warranty Of Core Components | More Than 5 Years | Moving Type | Wheel Loader |
| Dimension(Long * Breadth * High) | 2206* 1160* 1233mm | Hydraulic Cylinder Brand | Xiandai |
| Hydraulic Valve Brand | Eougem | Bucket Capacity | 0.15cbm |
| Bucket Width | 1150mm | Engine Type | HGX690 |
| Max Working Height | 2143mm | Cooling Method | Air-cooled |
| Max Dumping Height | 1488mm | Max Dumping Distance | 348mm |
| Total Length Without Bucket | 1752mm | Max Lifting Force | 300kg |
| Highlight | Four Wheel Drive Loader,Front End Mini Skid Steer Loader,13.5HP Small Front End Loader |
||
Product Description
Four Wheel Drive Mini Loader Machine Mini Tractor Loader Mini Skid Loader Front End Loader Small Loader
Mini loader skid steer loader can change different attachments at job site, it can change just needs a few of minutes , to adapt to different working environment and job contents In this way, shoveling, stacking, lifting, digging, drilling, crushing, grasping,pushing, loosening soil, trenching, road cleaning can be respectively carried out. An auxiliary trailer can load all attachments to job site, do whatever you want to do.
It can be used for site clearing and project closing after large engineering machinery. The 4 in 1 bucket would better choice of attachment for this job, which is with pushing, shoveling,leveling and grabbing 4 functions.
Attachments can be: digger, auger, trencher, sweeper, backhoe, high dump bucket, tiller, lawn mower, hydraulic grapple fork, fork, 4 in 1 bucket, snow blower, leveler, angle blade, mixer, hydraulic breaker, trench filler, lawn aerator, sweeper with bucket,
stone bucket, trailer, standard bucket, ripper, stump grinder, wood chipper, multi-function tool etc.
|
Lifting Capacity KG
|
300
|
|
Engine Type
|
HONDA / Briggs & Stratton / Rato Engine
|
|
Engine Capacity(kw/Hp)
|
13.5HP
|
|
Displacement cm3/Number of cylinders
|
Single
|
|
Rotation speed per minute(rpm)
|
3600
|
|
Maximum torque NM/rpm
|
38.6/2500
|
|
Cooling method
|
Air-cooled
|
|
Fuel/Fuel tank capacity
|
Gasoline 95#/20L
|
|
Drive System
|
Hydraulic four-wheel drive
|
|
Speed(km/h)
|
0-6.5(By Scale)
|
|
Enhancement of capabilities(kg)
|
350
|
|
Traction force(kg)
|
409
|
|
Hydraulic drive system(L/bar)
|
35/200
|
|
Hydraulic oil tank capacity(L)
|
40
|
|
Standard Tires
|
22*11.00-8
|
|
Electrical system(V)
|
12
|
|
Battery Capacity(Ah)
|
45
|
|
Braking System
|
Hydraulic enclosed brake
|
|
Drive
|
Skid steering
|
|
Hydraulic Cylinder Thrust(KG)
|
600
|
|
Rising Force(KG)
|
300
|
|
Overall Dimensions(MM)
|
1525*1050*1258
|
|
Weight(KG)
|
640
|
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Mini Excavator, Road Roller, Loader, Spray Machine, Packing Machine
3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian
