Lifting Platform Mini Loader Machine 500kgs 1000kgs Mini Dumper Truck With Rubber Track
| Place of Origin | China |
|---|---|
| Brand Name | Jawell |
| Certification | Euro5/EPA |
| Model Number | JW-MLM-HT500Y-HT |
| Minimum Order Quantity | 1 set |
| Price | $4000--$4500 |
| Packaging Details | Wooden box |
| Delivery Time | 7-35days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 2000 pieces per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Engine Brand | B&S | Power | 10kw |
|---|---|---|---|
| Applicable Industries | Building Material Shops, Farms, Home Use, Construction Works , Construction Agriculture | Type | Mini Dumper |
| Warranty | 1year | Machine Weight | 500 Kg |
| UNIQUE SELLING POINT | High Operating Efficiency | Machinery Test Report | Provided |
| Video Outgoing-inspection | Provided | Warranty Of Core Components | 1 Year |
| Moving Type | Crawler Loader | Bucket Capacity | 0.15cbm |
| Hydraulic Cylinder Brand | China Brand | Hydraulic Valve Brand | China Brand |
| Item Name | Mini Dumper Mini Loader | Loading Capacity | 600kgs |
| Keyword | Mini Dumper Mini Loader | Emission | Euro5/EPA |
| Overall Dimension(mm) | 1895mm*770mm*1220mm | ||
| Highlight | Lifting Platform Mini Loader Machine,Mini Loader Machine 500kgs,1000kgs Mini Dumper Truck |
||
Product Description
Lifting Platform Mini Loader Machine 500kgs Mini Dumpe Truck 1000kgs Rubber Track All-Terrain Transporter Crane Truck
Mini Dumper Truck Mini Dumper
HT500Y-5 Self-Loading Mini lift dumper ,Mini lifting dumper ,self loading truck loader
1. max loading capacity 550kg
2. Max loading weight horizontal transport : 1000kg
3. Engine Model:BRIGGS STRATTON 420 CC 13.5hp ,EPA Euro 5
4. Max lifting discharge height: 1500(MM)
5. Walking Speed:3(km/h)
| Engine | ||
| Engine Model | Briggs&Stratton Pioneer | |
| Engine Type | Single cylinder, OHV, 4-stroke, air cooling | |
| displacement | 203CC | |
| Rated Power | 6.5HP/3600rpm | |
| Fuel Type | 92 # Gasoline | |
| Fuel Tank capacity | 3.6L | |
| Weight | ||
| Total Weight | 550KG | |
| Maximum load | 500KG | |
| Machin size(Without pedal, without bucket) | 1570*880*1450MM | |
| Bucket size with foot pedal: | 2050*880*1450MM | |
| Container size: | 1050*730*730MM | |
| Chassis width: | 700MM | |
| Lift data | ||
| Maximum rise | 1020mm | |
| Tipping height | 970mm | |
| Tipping interval | 220mm | |
| Track data | ||
| track width: | 180MM | |
| Track grounding length: | 1000MM | |
| Chassis ground clearance: | 110MM | |
| Hopper | ||
| Cargo box Capacity | 200dm³ | |
| Tipping Systme | Hydraulic Tipper | |
| Tilting Angle | 100° | |
| Walk | ||
| Walking Speed | 2.88km/h | |
| Minimum Turning radius | 1150MM | |
| Track gauge | 520MM | |
| Climbing abillty | 20° | |
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q:How can we guarantee quality?
A:Each product will be strictly inspected before being sold and most of our products are tested and certified.
Q:What is the minimum order quantity?
A:Most of the spot products have no minimum order quantity and can be purchased in any quantity.If you want to customize, the minimum order depends on your customization requirements.
Q:What's the lead time?
A:1~2 weeks after all the payment.
Q:Do you provide samples?
A:Yes, we can provide free samples and you only need to pay the shipping cost.
Q:What's the available color?
A:You can see the color of our spot products on the website. If you need different colors, we can customize it for you.
Q:What's your payment terms?
A:We are willing to accept Alibaba Trade Insurance and T/T. Shipment after all the payment.
