Fully Hydraulic Compact Mini Loader Machine Hydraulic Travel Lift 800kg Small Loader Mini Loader For Sale
| Place of Origin | China |
|---|---|
| Brand Name | Jawell |
| Certification | CE ISO GS EMC |
| Model Number | JWSML01SG |
| Minimum Order Quantity | 1piece |
| Price | 11000$~13000$ |
| Packaging Details | Standard |
| Delivery Time | 7-35days |
| Payment Terms | L/C, D/P, Western Union, MoneyGram |
| Supply Ability | 500pieces/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Mini Loader Small Loader Compact Loader | Power | 18.5kw(24.8BHP) |
|---|---|---|---|
| Maximum Torque | 67Nm | Bucket | 0.3m3 |
| Tipping Load In Shovel, Vehicle | 800kg | Operating Weight | 1470kg |
| Drive Mode | Fully Hydraulic | ||
| Highlight | 800kg Compact mini loader Machine,Fully Hydraulic Compact mini loader Machine |
||
Product Description
Fully Hydraulic Compact Mini Loader Machine Hydraulic Travel Lift 800kg
Small Loader Mini Loader For Sale
Mini Loader Excellent performance
- Perkins power features low energy consumption and environmental protection.
- The closed hydrostatic system has the feature of lower energy consumption.
- Simple quick-change construction can meet multipurpose operation of users.
- The integrated multi-functional control handle makes operation simple.
- The monitor has the LED showing of fuel level by stages.
- The unique frame hinge type is compacted and durable.
- The widely applied broad-face tyre and damping seat is safe and comfortable.
- Small working radius, mobile and flexible.
Specifications and overall dimensions
| Model | JW403J-11 |
| Rated power | 18.5kw(24.8BHP) |
| Rated speed | 2800rpm |
| Maximum torque | 67Nm |
| The ratio of fuel consumption | 252g/kwhr |
| Dimensions | |
| Body length | 2750mm |
| Body width(reverse tyre) | 1150mm |
| Body height | 2050mm |
| Minimum ground clearance | 200mm |
| Maximum dumping height | 2000mm |
| Dumping reach | 600mm |
| Wheel base | 1340mm |
| Performance parameters of the machine | |
| Bucket | 0.3m3 |
| Tipping load in shovel, vehicle straight raight straight 798kg | 798kg |
| Tipping load in shovel, vehicle at 68° | 498kg |
| Operating weight | 1470kg |
| The sum of the work device | 8s |
| Driving speed | 0-17km/h |
| Minimum turning-circle radius | |
| Outside face of bucket | 1989mm |
| Outside face of tyre | 1469mm |
| Tyre specifications | 27*8.5-15TL/26x12-12 |
| Maximum turning angle | ±68° |
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Mini Excavator, Road Roller, Loader, Spray Machine, Packing Machine
3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian
