2.8ton With Factory Price Selling Skid Steer Loader High Efficiency With Powerful Engine And Low Price
| Place of Origin | China |
|---|---|
| Brand Name | Jawell |
| Certification | CE |
| Model Number | JWAT50 |
| Minimum Order Quantity | 1 piece |
| Price | $19225--$25617 |
| Packaging Details | Export wooden packaging |
| Delivery Time | 7-35days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 1000 pieces per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Max Speed | 10km/H | Rated Flux (L/Min) | 80 |
|---|---|---|---|
| Rated Power (Kw) | 45 | Fuel Tank Capacity (L) | 50 |
| Dead Weight (Kg) | 2700 | Self Weight Bucket (Kg) | 2800 |
| Bucket Capacity (M³) | 0.4 | Overall Operating Height (mm) | 3660 |
| Dumping Angle At Maximum Height(° ) | 40 | Dumping Height(mm) | 1990 |
| Dumping Reach(mm) | 1040 | ||
| Highlight | Powerful Engine Skid Steer Loader,2.8ton Skid Steer Loader,High Efficiency Skid Steer Loader |
||
Product Description
Product Description
Mini Skid Steer Loader Diesel Skid Steer Wheel Loader Automatic For Sale
The AT50 model skid steer loader is a powerful and versatile machine designed to handle a wide range of tasks with ease. With its robust construction and compact size, it excels in tight spaces and challenging terrain. Equipped with a reliable engine and advanced hydraulic system, the AT50 model delivers impressive performance and exceptional lifting capabilities. Its ergonomic design provides the operator with comfort and convenience, featuring intuitive controls and excellent visibility for enhanced productivity and safety. Whether it's moving heavy materials, clearing debris, or performing landscaping tasks, the AT50 model skid steer loader is a reliable workhorse that consistently delivers results.
Product Parameters
| Model | AW45 | AW65 | AT50 | AT65 |
| Operating load (kg) | 700 | 1050 | 700 | 1000 |
| Max Speed(km/h) | 10 | 10 | 10 | 12 |
| Rated flux (L/min) | 80 | 89 | 80 | 89 |
| Tire(track) model | 10-16.5NHS | 12-16.5NHS | 300X52.5 | 300X52.5 |
| Rated power (Kw) | 42KW | 55KW | 45KW | 55KW |
| Fuel tank capacity (L) | 70 | 75 | 50 | 90 |
| dead weight (kg) | 2600 | 3300 | 2700 | 3700 |
| self weight bucket (kg) | 2700 | 3400 | 2800 | 3800 |
| Bucket capacity (m³) | 0.4 | 0.5 | 0.4 | 0.5 |
| Overall operating height (mm) | 4042 | 3987 | 3660 | 3900 |
| Height to bucket hinge pin (mm) | 3079 | 3018 | 2730 | 2970 |
| Hheight to top of cab (mm) | 2230 | 2295 | 2349 | 2409 |
| Height to bottom of level bucket(mm) | 2909 | 2862 | 2500 | 2790 |
| Without bucket length(mm) | 2325 | 2527 | 2170 | 2450 |
| Overall length with bucket(mm) | 3276 | 3428 | 3150 | 3400 |
| Dumping angle at maximum height(° ) | 37.5 | 32 | 40 | 40 |
| Dumping height(mm) | 2342 | 2410 | 1990 | 2270 |
| Dumping reach(mm) | 550 | 850 | 1040 | 1120 |
| Rollback o bucket on ground(° ) | 20.5 | 23 | 30 | 30 |
| Rollback of bucket at full height(° ) | 96.5 | 95 | 100 | 100 |
| Wheelbase(mm) | 991 | 1074 | 1230 | 1500 |
| Ground clearance(mm) | 185 | 205 | 230 | 200 |
| Angle of departure(° ) | 20 | 20 | 18.5 | 18.5 |
| Front turning radius without bucket(mm) | 1188 | 1320.5 | 1064 | 1230 |
| Front tuning radius(mm) | 2209.5 | 2096.5 | 1825 | 2010 |
| Rear tuning radius(mm) | 1481.5 | 1647.5 | 1264 | 1720 |
| Rear axle to bumper (mm) | 929 | 1057 | 590 | 730 |
| Tread width (mm) | 1462.5 | 1498 | 1022 | 1482 |
| Width (mm) | 1726.5 | 1805 | 1422 | 1782 |
| Bucket width (mm) | 1742 | 1880 | 1700 | 1830 |
Detailed Photos
Packing Delivery
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Mini Excavator, Road Roller, Loader, Spray Machine, Packing Machine
3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian
