90HP 12 Gear Shifts Agricultural Tractor With Provided Machinery Test Report
| Place of Origin | Shandong China |
|---|---|
| Brand Name | Jawell |
| Certification | CE |
| Model Number | JW-904-YQ |
| Minimum Order Quantity | 1 unit |
| Price | $10600-12400 per unit |
| Packaging Details | Iron frame or iron frame with plywood |
| Delivery Time | 7-To be negotiated |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 200 units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Warranty | 3 Years/3000 Hours | Drive Type | Gear Drive |
|---|---|---|---|
| Fuel Capacity | 400 Gallons | Lights | LED Lighting Package |
| Rated Traction Force | 17500N | Starting Method | Electricity |
| Machinery Test Report | Provided | Transmission Box | Mechanic Gear Box |
| Highlight | 90HP Agricultural Tractor,12 Gear Shifts Agricultural Tractor |
||
Product Description
4WD 90HP 12 Gear Shifts Agricultural Tractor With Provided Machinery Test Report
Product Description:
904tractor , 90HP4WD, YTO engine, air-conditioned cab
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30,' two sets of hydraulicqutput, 11-inch double
acting clutch, imported Gramer seat, rear counterweight,Hydraulic auxiliary 7 5 L| oil tank,
PTO540/1000 or 540/760
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30,' two sets of hydraulicqutput, 11-inch double
acting clutch, imported Gramer seat, rear counterweight,Hydraulic auxiliary 7 5 L| oil tank,
PTO540/1000 or 540/760
Features:
- Product Name: Agricultural Tractor
- Pto Speed: 540/1000
- Starting Method: Electricity
- Gear Shifts: 12+12
- Drive Type: Gear Drive
- Horsepower: 90 Hp
Technical Parameters:
| Tractor Parameters |
Model | 904 | |||||||||
| Drive Type | 4WD | ||||||||||
| Overall Dimensions L×W×H(mm): | 4100x1950x2780 | ||||||||||
| Wheel Track (mm) | Front axle | 1400/1450/1500/1550 | |||||||||
| Rear axle | 1300-1800 | ||||||||||
| Wheel Bass(mm) | 2350 | ||||||||||
| Ground Clearance (mm) | 460 | ||||||||||
| Rated Traction Force(N) | 17500 | ||||||||||
| Construction Mass(kg) | 3700 | ||||||||||
| Theoretical Speed (km/h) |
Forward | 2.46—32.73 | |||||||||
| Reverse | 2.15—28.69 | ||||||||||
| Engine Specifications |
Model | 3E22RT51P904 | |||||||||
| Type | 4-Cylinder Vertical,water cooled,4 stroke cycle |
||||||||||
| Rated Power(kw/hp) | 76.2 | ||||||||||
| Rated Speed (rpm) | 2400 | ||||||||||
| Bore×Stroke (mm) | 90×100 | ||||||||||
| Total Displacement(L) | 2.55 | ||||||||||
| Drive System |
Clutch | 11" dual-stage | |||||||||
| Gear Box | 12+12 | ||||||||||
| Traveling Mechanism |
Tyre | Front | 11.2-24 | ||||||||
| Rear | 16.9-30 | ||||||||||
| Steering Gear | Full Hydraulic Steering | ||||||||||
| Brake | Disc type | ||||||||||
| Description | |||||||||||
| 904 tractor,90HP 4WD, Y T O engine , air-conditioned cab, 12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30, two sets of hydraulic oacting clutch, imported Gramer seat, rear counterweight,Hydraulic auxiliary 7 5 LPTO540/1000 or 540/760 |
utput, 11-inch double- oil tank, | ||||||||||
Packing and Shipping:
Packaging and Shipping of Agricultural Tractor
The Agricultural Tractor will be carefully packaged to ensure its safe arrival to our customers. Here is the packaging and shipping process:
Packaging Process:
- The Agricultural Tractor will be wrapped in a protective layer to prevent any scratches or damage during transportation.
- It will then be placed in a sturdy cardboard box with additional padding to provide extra protection.
- The box will be sealed and labeled with the product name, model number, and customer's address.
Shipping Process:
Once the Agricultural Tractor is packaged, it will be shipped using a reliable and efficient shipping service. Here are the steps we will take to ensure a smooth delivery:
- We will check all necessary documents and clearances for international shipments, if applicable.
- The tractor will be loaded onto a secure and well-maintained truck for land transportation.
- If the tractor is being shipped overseas, it will be loaded onto a cargo ship.
- During the shipping process, we will continuously monitor the tractor's progress and provide updates to the customer.
- Upon arrival at the destination, the tractor will be carefully unloaded and delivered to the customer's address.
At Agricultural Tractor, we take great care in packaging and shipping our products to ensure their safe arrival. If you have any questions or concerns about the packaging and shipping process, please don't hesitate to contact us. We are dedicated to providing the best service possible for our customers.
