Mechanic Gearbox Agricultural Tractor Equipment 70Hp With 12 12 Gear Shifts
| Place of Origin | Shandong China |
|---|---|
| Brand Name | Jawell |
| Certification | CE |
| Model Number | JW-AG704-YQ |
| Minimum Order Quantity | 1 unit |
| Price | $10400-12200 per unit |
| Packaging Details | Iron frame or iron frame with plywood |
| Delivery Time | 7-To be negotiated |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 200 units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Starting Method | Electricity | Transmission Box | Mechanic Gear Box |
|---|---|---|---|
| Rated Traction Force | 17000N | Lights | LED Lighting Package |
| Gear Shifts | 12+12 | Pto Speed | 540/1000 |
| Machinery Test Report | Provided | Horsepower | 70Hp |
| Highlight | Mechanic Gearbox Agricultural Tractor,Agricultural Tractor Equipment,Agricultural Tractor 70Hp |
||
Product Description
Mechanic Gear Box Agricultural Tractor With 12 12 Gear Shifts For Optimal Efficiency
Product Description:
704tractor , 70HP4WD, YTO engine ,air-conditioned cab,
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30, two sets of hydraulicoutput, 11-inch double
acting clutch, imported Gramer seat, rear counterweight,Hydraulic auxiliary 7 5 L oil tank,
PTO540/1000 or 540/760
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30, two sets of hydraulicoutput, 11-inch double
acting clutch, imported Gramer seat, rear counterweight,Hydraulic auxiliary 7 5 L oil tank,
PTO540/1000 or 540/760
Technical Parameters:
| Tractor Parameters |
Model | 704 | |||||||||
| Drive Type | 4WD | ||||||||||
| Overall Dimensions L×W×H(mm): | 4100x1950x2780 | ||||||||||
| Wheel Track (mm) | Front axle | 1400/1450/1500/1550 | |||||||||
| Rear axle | 1300-1800 | ||||||||||
| Wheel Bass(mm) | 2350 | ||||||||||
| Ground Clearance (mm) | 460 | ||||||||||
| Rated Traction Force(N) | 17000 | ||||||||||
| Construction Mass(kg) | 3700 | ||||||||||
| Theoretical Speed (km/h) |
Forward | 2.46—32.73 | |||||||||
| Reverse | 2.15—28.69 | ||||||||||
| Engine Specifications |
Model | 3E22RT51P904 | |||||||||
| Type | 4-Cylinder Vertical,water cooled,4 stroke cycle |
||||||||||
| Rated Power(kw/hp) | 76.2 | ||||||||||
| Rated Speed (rpm) | 2400 | ||||||||||
| Bore×Stroke (mm) | 90×100 | ||||||||||
| Total Displacement(L) | 2.55 | ||||||||||
| Drive System |
Clutch | 11" dual-stage | |||||||||
| Gear Box | 12+12 | ||||||||||
| Traveling Mechanism |
Tyre | Front | 11.2-24 | ||||||||
| Rear | 16.9-30 | ||||||||||
| Steering Gear | Full Hydraulic Steering | ||||||||||
| Brake | Disc type | ||||||||||
Features:
Packing and Shipping:
PACKAGING AND SHIPPING FOR AGRICULTURAL TRACTOR
When it comes to packaging and shipping our agricultural tractors, we prioritize safety, efficiency, and sustainability. We want to ensure that your tractor arrives at its destination in perfect condition and with minimal environmental impact.
PACKAGING
Our agricultural tractors are carefully packaged to protect them from any damage during transit. Each tractor is securely fastened onto a pallet and wrapped in protective material to prevent scratches and dents. We also use high-quality packaging materials to ensure the safety of delicate parts and components.
SHIPPING
We offer a variety of shipping options to best suit your needs. Our tractors can be shipped domestically and internationally through air, sea, or land. We work with trusted shipping companies to ensure timely and safe delivery of your tractor.
ENVIRONMENTAL CONSIDERATIONS
We are committed to reducing our carbon footprint and promoting sustainability in our packaging and shipping processes. We use eco-friendly materials for packaging and partner with shipping companies that prioritize environmental responsibility. Additionally, we offer recycling and disposal services for any packaging materials used.
At Agricultural Tractor, customer satisfaction is our top priority. That's why we carefully package and ship our tractors to ensure they arrive in perfect condition. In the rare event of any damage during shipping, please contact us immediately so we can resolve the issue and ensure your satisfaction.
Thank you for choosing Agricultural Tractor. We look forward to providing you with a high-quality, safely packaged, and environmentally friendly tractor.
